Description
Zeiss Cirrus 5000 HD-OCT provide highest resolution visualization capabilities and track retinal pigment epithelial integrity using Advanced RPE Analysis and assess glaucomatous loss with Ganglion Cell Analysis
Cirrus 5000 HD-OCT come with features an active eye-tracking mechanism that able to trace and compensate eye motion in real time and FastTrac retinal tracking to reduces eye motion artifacts without sacrificing patient
Cirrus 5000 HD-OCT come with version 9.5 software can acquire 68,000 scans per second with fundus photos
This Cirrus completely refurbished by Zeiss trained technician
The new updated system features state-of-the-art hardware and software based on a fast 64-bit Windows 7 computer, a significantly accelerated OCT camera system, a much larger 19-inch monitor, and a wireless mouse and mouse Keyboard. This results in faster processing with shorter times for the patient and ophthalmologist.
The Cirrus 5000 HD-OCT scan speed is between 27,000 and 68,000 per second.
Last but not least, there was an extraordinarily wide range of tools for diagnosing glaucoma, maculopathies, and the anterior segment without having to install an additional lens.
Specifications
- OCT Imaging
- Methodology: Spectral domain OCT
- Optical source: Superluminescent diode (SLD), 840 nm
- Scan speed: 27K- 68K A-scans per second
- A-scan: 2.0 mm (in tissue), 1024
- Axial resolution: 5 μm (in tissue)
- Transverse resolution: 15 μm (in tissue)
Fundus Imaging
- Methodology: Line scanning ophthalmoscope (LSO)
- Live fundus image: During alignment and during OCT scan
- Optical source: Superluminescent diode (SLD), 750 nm
- Field of view: 36 degrees W x 30 degrees H
- Frame rate: > 20 Hz
- Transverse resolution: 25 μm (in tissue)
Iris Imaging
- Methodology: CCD camera
- Resolution: 1280 x 1024
Include
- New Printer
- Mouse
- Keyboard
- Warranty Table
- Table
- all peripherals.
